Code : 1632432630018-en
STABILITY OF CYLINDER POSITION ENSURED BY LARGE HEXAGONAL BASE. UNIFORM WALL THICKNESS OF THE CYLINDER ELIMINATES WEDGE READING ERROR. CALIBRATION FOR FILLING (IN) AT REFERENCE TEMPERATURE +20 °C. ACCURACY CLASS A. TYPICAL USE: DILUTION OF SOLUTIONS, MIXING OF SEVERAL COMPONENTS IN SPECIFIED RATIOS.
| Kapacita ml | Dělení | Meze přesnosti +-ml | d (mm) | h (mm) | SJ | Počet kusů | Code |
|---|---|---|---|---|---|---|---|
| 5 | 0-1 | 0-05 | 12-9 | 115 | 10-19 | 10 | 1652 AMPN |
| 10 | 0-2 | 0-1 | 15-5 | 135 | 10-19 | 10 | 1652 AMPN |
| 25 | 0-5 | 0-25 | 21-3 | 160 | 14-23 | 10 | 1652 AMPN |
| 50 | 1 | 0-5 | 26 | 195 | 19-26 | 10 | 1652 AMPN |
| 100 | 1 | 0-5 | 31-3 | 240 | 24-29 | 10 | 1652 AMPN |
| 250 | 2 | 1 | 40-7 | 320 | 29-32 | 10 | 1652 AMPN |
| 500 | 5 | 2-5 | 53-2 | 380 | 34-35 | 10 | 1652 AMPN |
| 1000 | 10 | 5 | 67 | 465 | 45-40 | 4 | 1652 AMPN |
| 2000 | 20 | 10 | 85 | 535 | 45-40 | 3 | 1652 AMPN |
